S412 Solid Wire Rope Thimble – Forged Strength for Heavy-Duty Marine and Lifting Applications

Solid Forged Structure for Maximum Strength

The S412 Solid Wire Rope Thimble is precision-forged to create a one-piece solid structure that provides unmatched durability.

Each thimble is made from high-tensile carbon steel or AISI 316 stainless steel, with forging pressure exceeding 1,000 tons to eliminate internal voids and enhance structural density.

Contact us for detailed metallurgical data and breaking load test results for your specific wire rope sizes.

Optimized Geometry for Secure Rope Seating

The thimble’s compact solid design offers exceptional rope seating stability, reducing deformation and wear.

The internal groove radius is precision-machined to match rope diameters from 13mm to 35mm, ensuring tight seating and even stress distribution during dynamic loads.

Request a technical drawing or 3D model to evaluate fitment for your lifting and mooring assemblies.

Superior Corrosion Resistance for Marine and Offshore Use

Built for long-term exposure in harsh marine conditions, the S412 thimble maintains integrity even under saltwater contact.

Available with hot-dip galvanized coating, color painted or electropolished AISI 316 finish for superior corrosion performance in offshore environments.

Ask our team which corrosion protection finish best suits your marine or offshore rigging project.

High Load-Bearing Capability and Certified Safety

Engineered for extreme loads, this thimble delivers reliable performance under tension and shock loads.

Proof load tested to 1.5x working load limit (WLL) and compliant with EN 13411-1 and ISO 9001:2015 standards.

Send us your WLL requirements to receive certified inspection reports and product traceability documentation.

Versatile Application Across Marine, Lifting, and Industrial Fields

The S412 Solid Thimble is used across diverse heavy-duty industries where reliability is critical.

Ideal for ship mooring lines, offshore cranes, wire rope slings, and industrial hoisting equipment.

Reach out today to match the right thimble size for your lifting or mooring configurations.
