#2 MARINE EQUIPMENT

Twisted Rope

Product attributes :

Features

Traditional twisted rope construction providing reliable strength and flexibility.
Excellent flexibility and easy handling for marine, mooring and general rope applications.
Good abrasion resistance and durability for repeated use in demanding working environments.
Available in different strand constructions, materials, diameters and lengths.
Suitable for mooring, towing, anchoring, lifting assistance and general marine applications.
Available with customized eye splices, thimbles, protective sleeves and rope-end terminations.
Manufactured according to customer specifications and application requirements.

Description

Twisted rope construction made by twisting multiple strands together to provide a balanced combination of strength, flexibility and durability. Depending on the application, twisted rope can be manufactured in different strand configurations, materials, diameters and lengths.

Twisted ropes are widely used in marine operations, mooring, towing, anchoring and general industrial applications where reliable rope performance and easy handling are required. Different materials and constructions can be selected to meet specific requirements for strength, abrasion resistance, flexibility and environmental conditions.

We supply Twisted Rope in customized specifications, including different diameters, lengths, strand constructions, eye splices and protective fittings.

Inquiry Now

Product Details
Related Products
Online Message

Product Details

TWISTED ROPE 3-4-6 STRAND

Twisted rope is produced by HTPP, PE, PP Daline, Polyester, PP/polyester mixed or Polyamide (Nylon).

It's small size and commonly used in ship mooring, shipbuilding, deep sea farming,pelagic fishing,mine, water conservancy projects, industrial lifting, etc.

Dia. mm	Size	pp rope		powerdan rope		power-mixed®rope		nylon rope		polyethylene rope		polyester rope
Dia. mm	Inch Cir.	220m weight	MBL ton	220m weight	MBL ton	220m weght	MBL ton	k220m weight	MBL ton	220m weight	MBL ton	220m weight	MBL ton
4	1-2	1.32	0.21	1.68	0.30	2.00	0.30	2.31	0.32	1.78	0.20	2.60	0.30
6	3-4	3.74	0.60	3.78	0.70	4.70	0.90	4.95	0.75	4.00	0.40	6.00	0.56
8	1	6.60	1.06	6.72	1.30	8.30	1.60	8.80	1.35	7.20	0.70	10.60	1.02
10	1-1/4	9.90	1.56	10.50	1.80	12.40	2.40	13.60	2.08	10.80	1.09	16.70	1.59
12	1-1/2	14.30	2.21	15.12	2.60	17.90	3.40	19.60	3.00	15.80	1.54	24.20	2.27
14	1-3/4	20.00	3.05	20.58	3.60	25.00	4.70	27.00	4.10	21.00	2.09	32.60	3.18
16	2	25.30	3.78	26.88	4.50	31.60	5.90	35.00	5.30	28.00	2.80	43.00	4.10
18	2-1/4	32.50	4.82	34.02	5.70	40.60	7.50	44.00	6.70	35.00	3.50	54.00	5.15
20	2-1/2	40.00	5.80	42.00	6.80	50.00	9.00	54.00	8.30	44.50	4.30	67.00	6.40
22	2-3/4	48.40	6.96	50.82	8.20	60.50	10.70	66.00	10.00	53.00	5.10	81.00	7.60
24	3	57.00	8.13	60.48	9.60	71.30	12.60	78.00	12.00	65.00	6.10	96.00	9.10
26	3-1/4	67.00	9.41	70.98	11.10	83.80	14.60	92.00	14.00	72.00	7.00	113.00	10.70
28	3-1/2	78.00	10.70	82.32	12.60	97.50	16.60	107.00	15.80	86.00	8.20	131.00	12.20
30	3-3/4	89.00	12.20	94.50	14.40	111.30	18.90	122.00	17.80	101.00	9.50	150.00	13.70
32	4	101.00	13.50	107.52	15.90	126.30	20.90	139.00	20.00	115.00	10.70	171.00	15.70
36	4-1/2	129.00	16.90	136.08	19.90	161.30	23.30	176.00	24.90	145.00	13.40	216.00	19.40
40	5	158.00	20.50	168.00	24.20	200.00	26.20	218.00	30.00	173.00	16.30	267.00	24.00
44	5-1/2	194.00	24.60	203.28	29.00	245.00	28.80	264.00	35.80	209.00	19.60	323.00	28.50
48	6	229.00	28.60	241.92	33.70	290.00	32.10	312.00	42.00	253.00	22.80	385.00	33.60
52	6-1/2	268.00	33.10	283.92	39.10	330.00	35.10	365.00	48.80	290.00	26.40	451.00	39.20
56	7	312.40	39.59	329.27	50.50	393.80	62.04	442.20	61.53	345.40	30.51	523.60	48.57
60	7-1/2	358.60	45.41	378.00	58.28	441.10	70.54	497.20	68.95	398.20	34.95	600.60	55.44
64	8	407.00	51.33	430.08	65.20	497.20	79.05	554.40	77.14	451.00	39.39	684.20	62.83
65	8-1/8	420.42	52.96	443.94	67.25	512.60	81.43	572.00	79.59	465.85	40.64	706.20	63.22
70	8-3/4	487.74	61.33	514.92	77.49	591.80	93.81	664.40	91.83	540.09	46.89	817.30	72.78
72	9	514.80	64.59	544.32	81.58	624.80	99.06	726.00	97.65	569.80	49.39	864.60	77.00
75	9-3/8	561.66	70.10	590.94	88.59	677.60	106.93	761.20	102.39	620.95	53.52	937.86	83.52
80	10	6400.20	79.39	671.99	100.38	767.80	120.07	886.60	121.31	706.20	60.41	1067.00	98.48
85	10-5/8	722.70	89.29	758.93	113.77	865.42	135.70	979.00	135.32	798.33	68.00	1205.60	107.92
88	11	772.20	95.20	813.12	121.80	924.00	145.08	1051.60	145.35	853.60	72.55	1291.40	115.00
90	11-1/4	808.50	99.69	850.92	124.42	968.00	151.84	1097.80	151.74	853.60	72.55	1350.80	120.29
95	11-7/8	899.14	111.02	947.94	138.86	1078.00	168.72	1223.20	169.07	997.10	84.29	1507.00	132.81
96	12	915.20	113.27	967.67	142.80	1100.00	172.10	1251.80	173.60	1014.20	85.50	1537.80	135.52
100	12-1/2	997.70	120.92	1050.00	154.35	1194.60	187.11	1355.20	186.69	1100.44	92.80	1667.60	149.28
