JIS F7121 Marine Simplex Water Strainer
JIS F7121 Marine Simplex Water Strainer
Brand: RM
Pressure: 5K
Size: DN25-DN100
Material: cast iron,cast steel
Type: Water Strainer
Media: Water
Our JIS F7121 Marine Simplex Water Strainer is manufactured according to Japanese standards, ensuring durability and excellent performance in ship systems.
Constructed with marine-grade cast steel, cast iron, or bronze, the strainer provides strong resistance to seawater corrosion and long-term reliability.
Product Details
| SIZE | φd | L | L1 | H | H1 | 5k FF Flange | |||
| φD | φC | t | n-φh | ||||||
| 25A | 25 | 170 | 85 | 180 | 75 | 95 | 75 | 14 | 4-12 |
| 32A | 32 | 190 | 95 | 215 | 85 | 115 | 90 | 16 | 4-15 |
| 40A | 40 | 190 | 95 | 215 | 85 | 120 | 95 | 16 | 4-15 |
| 50A | 50 | 200 | 100 | 240 | 100 | 130 | 105 | 16 | 4-15 |
| 65A | 65 | 250 | 125 | 305 | 152 | 155 | 130 | 18 | 4-15 |
| 80A | 80 | 270 | 135 | 340 | 154 | 180 | 145 | 18 | 4-19 |
| 100A | 100 | 320 | 160 | 400 | 185 | 200 | 165 | 20 | 8-19 |
