JIS F7333 Marine Cast Iron Globe Hose Valve
Marine Cast Iron Globe Hose Valve JIS F7333B 5K/10K
Standard: JlS F7301,7302,7303,7304,7351,7352,7409,7410
Pressure: 5K,10K
Size: DN50 DN65
Material: cast iron,cast steel,forged steel,brass,bronze
Type: globe valve,angle valve
Media: Water
Application: Water piping
Design standard: JIS F7333
Test standard: JIS 7400-1996
Hydraulic test pressure:
5K: valve body -1.05Mpa
valve seat -0.77Mpa
10K: valve body -2.1Mpa
valve seat -1.54Mpa
Product Details
| DN | K | d' | L | D | C | n-d | t | H | D2 | d3 | L1 | L2 | Weight kg | ||||||||
| 50 | 5 | 50 | 165 | 130 | 105 | 4-15 | 16 | 270 | 160 | M64×2 | 105 | 110 | 14.7 | ||||||||
| 10 | 50 | 170 | 155 | 120 | 4-19 | 20 | 285 | 160 | M64×2 | 110 | 115 | 18.9 | |||||||||
| 65 | 10 | 65 | 200 | 175 | 140 | 4-19 | 22 | 310 | 200 | M80×2 | 135 | 140 | 28.2 | ||||||||
| Nominal Pressure | 5kgf/cm²(0.49Mpa) | ||||||||||||||||||||
| Seal Pressure | 7.7kgf/cm²(0.76Mpa) | ||||||||||||||||||||
| Intensity Pressure | 10.5kgf/cm²(1.03Mpa) | ||||||||||||||||||||
| Medium | Max Pressure kgf/cm² | ||||||||||||||||||||
| Flow water | 5kgf/cm²(0.49Mpa) | ||||||||||||||||||||
| Lenitic water≤120° | 7kgf/cm²(0.69Mpa) | ||||||||||||||||||||
The JIS F7333 Marine Globe Hose Valve is manufactured from high-grade cast iron, offering excellent strength and durability for marine environments.
This valve is specifically designed for hose connections on ships, providing reliable shut-off and flow control in marine pipeline systems.
Built in full accordance with JIS F7333 specifications, ensuring compatibility and safety for shipbuilding and offshore applications.
The valve is offered in both 5K and 10K pressure classes to meet different ship pipeline system requirements and safety standards.
With special coating and marine-grade materials, this cast iron globe hose valve resists corrosion and maintains reliable performance at sea.
