#2 MARINE EQUIPMENT

JIS F7371 Marine Bronze Swing Check Valve 5K

Product attributes :

Marine Bronze Swing Check Valve 5K

Brand: RM

Standard: JIS F7371

Pressure: 5K,10K

Size: DN15-DN40

Material: cast iron,cast steel,forged steel,brass,bronze

Type: swing check valve

Media: Water,Oil,Steam


Our JIS F7371 Marine Bronze Swing Check Valve 5K is manufactured with high-grade bronze to ensure reliable sealing and performance in marine and ship pipelines.

This swing check valve fully complies with JIS F7371 standards, offering excellent compatibility for shipbuilding and marine engineering projects worldwide.

Built with marine-grade bronze, this valve provides outstanding resistance to seawater corrosion, ensuring long-lasting service in harsh marine environments.

Product Details

false



SIZEφdLH5K FF FlangeWeight
(kg)
φDφCtn-φh
25A25 110 69 95 75 10 4-122.24
32A32 130 79 115 90 12 4-153.07
40A40 140 93 120 95 12 4-154.34


NO.PartsMaterial
1BodyCAC406(BC6)
BonnetCAC406(BC6)
DiscCAC406(BC6)
Hinge pinC3604
PlugSUS304
GasketPTFE
