JIS KS91A -21 Air Vent Head

Product attributes :

Cast Iron JIS Air Vent Head, JIS KS91A-121 Air Vent Head

1.Application

Its function is to continuously filter the solid impurities in the system at work, maintain the cleanliness of the system medium, reduce the failure rate of the system components, and extend the service life of the system media and equipment.

2.Features

(1). Its convenient to use in application.

(2). Manufactured according to JIS F7400 standards. The valve material can be chosen by customers.


Air Vent Head also can be called as air pipe head, is used as theventilation of the oil tank or water tank on the vessel.

Flange size as per JlS B2220-5K

The flange size also can be manufactured according to 10K, 16K


Product Details


S/NNameMaterialS/NNameMaterial
Hex BoltSTS304Screen CoverSS400
CoverSS400Float DiscSTS304
PackingNBR10 Hex BoltSTS304
BodyFC200,FCD45011 PackingNBR
Hex BoltSTS30412 Spring WasherSTS304
Rubber RingNBR13 Guide BoltSTS304
Wire ScreenSTS304





DND2D3HrHiTNAA3RWeight
kg
50 105 130 175 127 14 4-φ15179 139 135 7.4
65 130 155 204 164 14 4-φ15205 160 146 12.6
80 145 180 244 176 14 4-φ15237 188 156 16
100 165 200 220 160 16 8-φ19245 155 250 23
125 200 235 250 180 16 8-φ19270 180 288 34
150 230 265 285 208 18 8-φ19316 216 330 47
200 280 320 365 269 20 8-φ23394 274 432 72
250 345 385 430 314 22 12-φ23485 325 546 120
300 390 430 530 367 22 12-φ23550 384 616 178
350 435 480 570 415 24 12-φ23661 425 714 196
400 495 540 640 475 24 12-φ23703 457 749 235
450 555 605 713 522 24 12-φ23816 510 836 298
